KEYSTROKES FOR SETPOINT SETUP
If the MENU key does not work, see Section 9 “Enabling & Locking Out Menu Items.”
ALSEt
Alarm Setup for
relays 1 & 2 if
detected.
Press until
ALSEt is displayed.
00000
Relay open or closed
when in alarm state.
0 AL1 relay closed AL2 relay closed
1 AL1 relay open AL2 relay closed
2 AL1 relay closed AL2 relay open
3 AL1 relay open AL2 relay open
00000
Alarm latching or non-
latching (auto reset).
See Glossary.
0 AL1 non-latching AL2 non-latching
1 AL1 latching AL2 non-latching
2 AL1 non-latching AL2 latching
3 AL1 latching AL2 latching
00000
Alarm state occurs at
or above setpoint, or
below setpoint, or is
disabled. Front panel
indicator lights come
on in alarm state,
0 AL1 at or above AL2 at or above
1 AL1 below AL2 at or above
2 AL1 disabled AL2 at or above
3 AL1 at or above AL2 below
4 AL1 below AL2 below
5 AL1 disabled AL2 below
6 AL1 at or above AL2 disabled
7 AL1 below AL2 disabled
8 AL1 disabled AL2 disabled
00000
Hysteresis mode or
band deviation mode.
See Glossary.
0 AL1 band deviation AL2 band deviation
1 AL1 split hysteresis AL2 band deviation
2 AL1 band deviation AL2 split hysteresis
3 AL1 split hysteresis AL2 split hysteresis
4 No deviation or hysteresis in menu.
5 AL1 span hysteresis AL2 band deviation
6 AL1 span hysteresis AL2 split hysteresis
7 AL1 span hysteresis AL2 span hysteresis
00000
Number of consecutive
readings in alarm zone
to enter alarm state.
0 After 1 reading 4 After 16 readings
1 After 2 readings 5 After 32 readings
2 After 4 readings 6 After 64 readings
3 After 8 readings 7 After 128 reading
ALS34
Alarm Setup for
relays 3 & 4 if
detected.
00000
Relay open or closed
when in alarm state.
0 AL3 relay closed AL4 relay closed
1 AL3 relay open AL4 relay closed
2 AL3 relay closed AL4 relay open
3 AL3 relay open AL4 relay open
00000
Alarm latching or non-
latching (auto reset).
0 AL3 non-latching AL4 non-latching
1 AL3 latching AL4 non-latching
2 AL3 non-latching AL4 latching
3 AL3 latching AL4 latching
