Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1
AttachingtheHandle
NoPartsRequired
Procedure
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removethehandleknobsfromthemachinehousing
(Figure3).
Important:Routethecablestotheoutsideof
thehandleasyouinstallthehandle.
1
g017343
Figure3
1.Handleknob(2)
2.Aligntheholesintheendsofthehandlewiththose
inthemachinehousingandlooselyscrewthehandle
knobsbackin.
3.Movethehandletotheoperatingpositionand
tightenthehandleknobsastightlyasyoucan.
Figure4
2
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmowerdoesnotcomewithoilintheengine.
1.Removethedipstick(Figure5).
Figure5
2.Slowlypouroilintotheoillltubeuntiltheoil
levelreachestheFulllineonthedipstick(Figure5).
Donotoverll.(Max.ll:22oz.(0.65l),type:
10W-30orSAE30detergentoilwithanAPIservice
classicationofSJorhigher.)
Note:Eachtimeyouchecktheoillevel,removethe
dipstickandwipeitclean,insertitintotheoilller
neck(butdonotscrewitin),thenremoveitagain
andcheckthelevel(Figure5).
Note:Ifyouoverlltheengine,poursomeoilout
ofitasdirectedinChangingtheEngineOil.
3.Installthedipsticksecurely.
5
