5
3352-942 Rev B
Setup
Note: Remove and discard the protective plastic
sheet that covers the engine.
Unfolding the Handle
1. Move the handle rearward and hold the upper
handle in place.
m-7950
Note: The handle will click into position.
2. Tighten the upper
handle knob as tight as
you can.
m-7919
Filling the Engine with Oil
Your mower does not come with oil in the engine,
but it does come with a bottle of oil.
1. Remove the dipstick.
m-7951
m-7951/m-5571
2. Slowly pour oil into the oil fill tube until the oil
level reaches the Full line on the dipstick. Do not
overfill. (Max. fill: 20 oz., type: SAE 30W detergent
oil with an API service classification of SF, SG, SH,
SJ, SL, or higher.)
3. Install the dipstick securely.
Important: Change the engine oil after the first
2 operating hours; change it yearly thereafter. Refer
to Changing the Engine Oil on page 12.
Before Operating
Danger
Gasoline is extremely flammable and explosive. A fire or explosion from gasoline can
burn you and others.
S To prevent a static charge from igniting the gasoline, place the container and/or
mower directly on the ground before filling, not in a vehicle or on an object.
S Fill the tank outdoors when the engine is cold. Wipe up spills.
S Do not handle gasoline when smoking or around an open flame or sparks.
S Store gasoline in an approved fuel container, out of the reach of children.
