Installing the Grass Bag
1. Rotate the latch rod
to the right and remove
the mulch plug.
m-7969
2. Route the starter rope around the lower rope
guide.
m-7956
Note: The lower rope guide releases the starter
rope when you pull the recoil start handle.
3. Insert the grass bag handle into the grooves at
the top of the mower.
m-7957
Removing the Grass Bag
1. Route the starter rope around the lower rope
guide.
m-7958
2. Lift the grass bag handle out from the grooves at
the top of the mower and remove the bag from the
mower.
m-7959
3. Insert the mulch plug
and rotate the latch rod
until it locks into place at
both the top and the
bottom (A).
A
m-7934
