Parts List
No. Description Q'ty
1 Side Log Support 2 1
2 Side Log Support 1 1
3
Locknut M8 4
4 Washer 8 8
5 Spring 2
6 Bush 2
7 Bolt 8.8 M8x210 2
8 Log Support C1 1
9 Bolt 8.8 M8x60 2
10 Bush 2 2
11 Lining Plate 4
12 Clip 2.5 2
13 Handle C1 2
14 Handgrip 4
15 Guard Ring C1 2
16 Screw M6x16 8
17 Washer 6 6
18 Locknut M6 8
19 Right Armguard C1 1
20 Retainer 1 1
21 Star Knob 4
22 Big Washer 8 11
23 Left Armguard C1 1
24 Bush 1 2
25 Pin C1 2
26 Star Knob M6 1
27 Cap 2
28 Retainer 2 1
29 Clamp 2
30 Splitting Pipe G5 1
31 Square Cap 1
32 Star Knob M5(black) 1
33 Upper Lining Plate 2-C 1
34 Upper Lining Plate 4 1
35 Upper Lining Plate 3 1
36 Upper Lining Plate 1 1
No. Description Q'ty
37 Screw M6x8 1
38 Locknut M4 2
39 Switch 1
40 Screw M4x60 2
41 Motor 1
42 Screw M6x10 1
43 Washer 16 7
44 Pull Rod G5 1
45 Lever C1 1
46 Cylinder C1 1
47 Circlip 22 4
48 Bolt M8x50 2
49 Nut M8 5
50 Main Frame C1 1
51 Short Shaft D 1
52 Tube C1 1
53 Star Knob (black) 1
54 Oil Plug A1 1
55 Washer Groupware 20 10
56 Oil Hose C1 1
57 Collar 1
58 Gear Pump C1 1
59 Nozzle C1 1
60 Oil Plug A2 2
61 Hose Clamp 18-23(24) 4
62 Oil Hose 13 1
63 Oil Hose C1 1
64 Nozzle A 1
65 CCA Valve 1
66 Oil Cap K 1
67
Oil Dipstick KG 1
68 Screw M8x90 2
69 Spring Washer 8 7
70 O-Ring 25x2.65 1
71 Big Washer 10 3
72 Motor Support 3
