37
PARTS LIST
Key Number Drawing Number Description Quantity
1 Motor Cover Assy. 1.0
2 111198146 Safety Key 1.0
3 PCB Assy. 1.0
4 Key Holder Assy. 1.0
5 Motor Drive Assy. 1.0
6 211068103 Wheel Assy. (5.51'') 4.0
7 Washer Assy. 1.0
8 Base Assy. 1.0
9 Front Axle Assy. 1.0
10 Ballast Assy. 1.0
11 Locating Ring 1.0
12 211049125 Blade 1.0
13 Bolt Assy. 1.0
14 Height Connecting Rod 1.0
15 Protective Plate Assy. 1.0
16 Rear Axle Assy. 1.0
17 Tension Spring 1.0
18 Rear Wheel Support 1.0
19 Safety Flap Assy. 1.0
20 Safety Door Spring 1.0
21 Safety Door 1.0
22 Lower Handle Assy. 1.0
23 211068109 Handle Knob Assy. 2.0
24 211068110 Grass Collection Bag 1.0
25 Upper Handle 1.0
26 Switch Box Assy. 1.0
27 Cable Clips 2.0
28 211062119 Battery 2.0
29 221024107 Charger 1.0
Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or
internal parts should only be done by a qualied service professional. Please contact your authorized
service dealer or Customer Service at 866-384-8432.
