LawnMaster NPTGSP2517A User Manual

2
Section Page
25cc-2 CYCLE GRASS TRIMMER
CONTENTS
PRODUCT SPECIFICATIONS
CONTENTS
PRODUCT SPECIFICATIONS
GENERAL SAFETY RULES
SYMBOLS
KNOW YOUR GRASS TRIMMER
ASSEMBLY
BATTERY PACK AND CHARGER
OPERATION
MAINTENANCE
ENVIRONMENTALLY SAFE BATTERY DISPOSAL
TROUBLESHOOTING
WARRANTY
EXPLODED VIEW
PARTS LIST
EXPLODED VIEW 25CC 2-CYCLE ENGINE
PARTS LIST 25CC 2-CYCLE ENGINE
NOTES
2
3-6
7-8
9-10
11-16
17-18
19-27
28-35
36
37-38
39
40
41
42
43
44-45
Engine Type
Engine Displacement Claimed / Rated
Power / Speed
Idle Speed
Max Torque / Speed
Fuel Tank Capacity
Fuel / Oil Ratio
Line Diameter
Cutting Width
Dry Weight
Battery Model No.
Battery Type
Charger Model No.
Charger Input
Charger Output
Charging Period (Battery Fully Discharged)
2-Stroke / Half Crank
25cc / 25 cm
3
0.8 kW / 7500 RPM
3000 ± 300 RPM
1.08 N.m / 6500 RPM
420 ml
40 : 1
0.095" (2.4 mm)
17" (430 mm)
13.21 lbs (5.99 kg)
7LB1331-C
7.2V Lithium-Ion, 1.3 Ah
YLS0042-T084045
100-240V ~ 50/60Hz 0.3A Max
8.4V 450 mA
4-6 Hours

LawnMaster NPTGSP2517A Specifications

General

Brand	LawnMaster
Model	NPTGSP2517A
Category	Trimmer
Language	English
