PARTS LIST

Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or

internal parts should only be done by a qualied service profrssional. Please contact your authorized

service dealer or Customer Service at 886-384-8432.

NPTGSP2517A MANUAL PARTS LIST

Key Number Part Number Description Quantity

1 321007101 25cc 2-Cycle Engine Assembly 1

2 321007102 Throttle-body & Starter Set 1

2.1 321007103 Throttle-body Set 1

2.2 321007104 Starter Set 1

2.2.1 321001105 Electric Switch 1

2.2.2 321007105 Starter Switch Assembly 1

2.2.3 321007106 Stop Switch Set 1

2.2.4 321007107 PCB Assembly 1

3 321008101 Connection Cover Assembly 1

4 321008102 Aluminum Upper Shaft 1

5 141004102 Cable Clamp 2

6 321001109 Handle Spacer 2

7 321008103 Assistant handle 1

8 321008104 aluminium connector assembly 1

9 321008105 Lower aluminium tube assy 1

10 321008106 Protector guard assembly 1

10.1 321008107 Small protector guard assembly 1

10.2 321008108 Large protector guard assembly 1

11 321008109 Spool Assembly 1

11.1 321008110 Compression spring 1

12 321008111 Gear Box Assembly 1

12.1 321008112 Screw M5*16 3

12.2 321008113 Cover Plate 1

13 321007116 7.2V 1.3Ah Battery 1

14 321001127 Charger 1

15 321001128 Shoulder Strap Clasp (Available Separately) 1

16 221003102 Shoulder Strap (Available Separately) 1

17 321004122 M5 Hexagon Socket Wrench 1

18 321004121 M6 Hexagon Socket Wrench 1

19 321007118 Hex Key 1

20 321007119 Socket Wrench 1
