PARTS LIST 25CC 2-CYCLE ENGINE

Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or

internal parts should only be done by a qualied service profrssional. Please contact your authorized

service dealer or Customer Service at 886-384-8432.

25CC 2-CYCLE ENGINE PART LIST

Key Number Part Number Description Quantity

1 321007184 Rear Engine Cover Assembly 1

2 321001139 Spark Plug 1

3 321007185 Cylinder Assembly 1

4 321007186 Ignition Coil Assembly 1

5 321007127 Insulation Sheet 1

6 321007188 Front Cover Assembly 1

7 321007189 Clutch Assembly 1

8 321007190 Connection Cover Assembly 1

9 321007191 Flywheel Assembly 1

10 321007149 Crankcase Assembly 1

11 321007192 Piston 1

12 321007123 Gasket 1

13 321007193 Fuel Tank 1

14 321007167 Fuel Cap 1

15 321007158 Carburetor Assembly 1

16 321007157 Washer 1

17 321007194 Carburetor Mount Assembly 1

18 321007155 Washer 1

19 321007159 Air Filter Base 1

20 321007196 Crankcase Cover 1

21 321007160 Choke Lever 1

22 321007161 Air Filter 1

23 321007162 Air Filter Cover 1

24 321007128 Mufer 1

25 321007129 Mufer Cover 1

26 321007130 Gasket 1

27 321007180 Screw Assembly 2

28 321007176 Washer 1

29 321007183 Screw 1

30 321007173 Spring 1
