6. Service Procedures
6.4 Using the Hood Fastener
The Hood Fastener can be used to keep a Fader or Central Panel in place while you work.
DO NOT attempt to open the frame without first disconnecting the mains supply.
1. Follow the previous section's steps to lift the panel.
You will see the Hood Fastener stowed safely within the frame.
2. Release the fastener from its catch, and place the "ball" end into the cut-out in the metal plate.
When you have finished working inside the frame, replace the hood fastener safely back into its catch, before
lowering the panel back into place.
