Operation (Web Browser Control)
Status
Status -> Frame
1. Select Status -> Frame:
The fields provide general status information on the pro8 frame:
Software Version - the current software versions. You can update the software from the
Settings -> Software Update menu.
UUID - Universally Unique Identifier. This number identifies your unit.
Power Supply 1 & 2 - the status of the two internal power supplies. In our example, power
supply 1 has been disconnected from the mains input. See Grounding & Power for more
details.
Temperature - various readings from the unit's temperature sensors. See Frame Installation
for recommended operating temperatures.
Fan Controller 1 & 2 - the fan speeds for each fan group.
License - the license status for each of the pro8 options.
