Installation & Configuration
Reference Settings
Reference Settings
The video and audio reference signals for the pro8 are selected from the Reference Setting options
in the Timing menu.
The system can be referenced to:
Analog Genlock High Definition Tri-Level Sync (SMPTE-274M/296M) - connected to the rear
panel's REF IN.
Standard Definition 1V Black & Burst (SMPTE-170M/318M) - connected to the rear panel's
REF IN.
SDI - from any of the 8 digital SDI inputs.
Internal
In Version 1.0, the audio reference is ALWAYS set to Follow Video. This means that the
system is clocked from a single reference source. In a future software release, you will be
able to clock video and audio signals independently.
To Next Page
