V_pro8 Manual V1.0/2 79
Operation (Web Browser Control)
SDI Out
High Definition Presets
16:9 - an incoming 16:9 image is unchanged.
4:3 Pillarbox - an incoming 4:3 image is sized to fit onto a 16:9 screen. The proportions of the
image are retained, but black bars appear at the sides of the screen. This option is also
known as "Barn Doors".
Remember to set the Status to On, to apply your new Converter and Aspect Ratio
settings.
