7
lci1.com 574-537-8900 Rev: 11.05.20
Floë 636 Integrated
Water Drainage System
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003522
Fig.9
RV Water System Diagram
12. Once all faucets and outlets have been drained, switch
o Floë and close the blue shuto valve. Leave all faucets
and outlets in the open position since fresh air is a good
sterilizer. Showers or faucets may have mixer valves and
therefore two pipes leading to them, both hot and cold.
Remember to leave in the open position but leave it set to
the middle between hot and cold.
13. Make sure to remove the water lter and empty
residual water since some lters have a drop bowl and the
pressurized air may drift over the top of the water.
14. In the winter, pour half a cup of antifreeze into the sink
and shower drain holes. Wipe o any spilled antifreeze to
avoid staining the chrome/gold nish.
