■ Usage Information
■ Basic Parameters
●Operational Frequency Parameter
FC 0.0
●4 Automatic Functions
AUH -
AU1 0
AU2 0
AU4 0
●Other Basic Parameters
CMOd 1
FMOd 0
FMSL 0
FM -
TyP 0
Fr 0
ACC 10.0
dEC 10.0
FH 60.0
UL 60.0
LL 0.0
VL 60.0
VLV 200/400
Title Function Adjustment range
Default setting
Note
Item Contents Item Contents
Date of setting/Name Customer name/End user name
Combined machine/Application
Machine nomenclature/product number
Motor manufacturer/Nomenclature
Motor capacity/Ratings
Inverter nomenclature/quantity HF-321-
Inverter product number/Serial number
Usage option Peripheral equipment used
Used control terminal block
Note
P24V, DRV, OM, FRQ, COM, FA, FB,
FC, +V, VRF, VRF2, COM, PCS, DFL, DFM, DFH, FR, RR, RST, COM
Used main circuit/Switch
Note
R, S, T, U, W, E/G, P, PR, N, PI VRF (V, I), FRQ (V, I), SW1 (SOURCE, PLC, SINK)
*Fill in as necessary
Note: Circle the symbol of terminal block used.
Operation
frequency of
operation panel
LL - UL (Hz)
Title Function Adjustment range
Default setting
Note
History function
Automatic
acceleration/
deceleration
Automatic torque
boost
Automatic function
setting
Displays parameters in
groups of five in the reverse
order to
that in which their
settings were changed.
(*Possible to edit)
0: Disabled (manual)
1: Automatic
2: Automatic (only at
acceleration)
0: Disabled
1: Automatic torque boost +
auto-tuning
2: Vector control+ auto-tuning
3: Energy saving+ auto-tuning
0: Disabled
1: Coast stop
2: 3-wire operation
3: External input UP/DOWN
setting
4: 4-20mA current input
operation
Title Function Adjustment range
Default setting
Note
Meter selection
Meter adjustment
Default setting
Forward/reverse
run selection
(Operation panel
operation)
Acceleration time 1
Deceleration time 1
Maximum frequency
Upper limit frequency
Lower limit frequency
Base frequency 1
Base frequency voltage 1
0: Output frequency
1: Output current
2: Set frequency
3: DC voltage
4:
Output voltage command value
5: Input power
6: Output power
7: Torque
8: Torque current
9: Motor cumulative load factor
10:
Inverter cumulative load factor
11: Braking resistor cumulative
load factor
12: Frequency setting value
(after PID)
13: VRF Input value
14: VRF2 Input value
15: Fixed output 1 (Output
current: 100%)
16: Fixed output 2 (Output
current: 50%)
17: Fixed output 3 (Other than
the output current: 100%)
18: Serial communication data
19: For adjustments (FM set
value is displayed.)
-
0: -
1: 50Hz default setting
2: 60Hz default setting
3: Don't choose
4: Trip record clear
5:
Cumulative operation time clear
6:
Initialization of type information
7: Don't choose
8: Standard default setting
(Initialization)
9: Cumulative fan operation
time record clear
0: Forward run
1: Reverse run
2: Forward run
(F/R switching possible)
3: Reverse run
(F/R switching possible)
0.0-3200 (s)
0.0-3200 (s)
30.0-500.0 (Hz)
0.5 - FH (Hz)
0.0 - UL (Hz)
25.0-500.0 (Hz)
200V class: 50-330 (V)
400/600V class: 50-660 (V)
Title Function Adjustment range
Default setting
Note
Command mode
selection
Frequency setting
mode selection 1
0: Terminal board
1: Operation panel
0: Built-in potentiometer
1: VRF
2: VRF2
3: Operation panel
4: Serial communication
5: UP/DOWN from external
contact
6: VRF+ VRF2 (Override)
Monitor Display
LED display on the control panel indicates numbers and
alphabets as below.
LED Display (Numbers)
LED Display (Alphabet)
0 1 2 3 4 5 6 7 8 9 -
0 1 2 3 4 5 6 7 8 9 -
Aa Bb C c Dd Ee Ff Gg H h I i Jj Kk Ll
A b C c d E F G H h I i j L
Mm Nn O o Pp Qq Rr Ss Tt Uu Vv Ww Xx Yy Zz
M n O o P q r S t U v y
To Next Page
