Rev:072409 Copyright © 2009 Liquid Combustion Technology, LLC LCT Engine Service Manual: 208cc, 291cc & 414cc 12
Torque Specifications
208cc 291cc 414cc
Item Torque (N.M) Torque (N.M) Torque (N.M)
Drain bolt 12 24 24
Oil sensor 8 8 8
Oil level cap 3 3 3
Spark plug 20-25 20-25 20-25
Carburetor studs 10-12 20 20
Exhaust studs 20-24 20-24 20-24
Pivot bolt M8 22-25 22-25 22-25
Connecting rod bolt 12-14 20 20-24
Flange bolt 18-24 18-24 18-24
Distributor M6*27 10-12 10-12 10-12
Flange bolt of cylinder head M8*55 36 40-42 48
Pivot adjusting nut for intake, exhaust valve 10 10 10
Flange bolt for head cover 10-12 10-12 10-12
The bolt for crankcase cover M6*14 10-12 10-12 10-12
Side plate M6*12 8 8 8
Governor support 8 8 8
Carburetor nut M6 7 8 8
Muffler nut M8 24 24 24
Rocker bolt 20-25 20-25 20-25
Cylinder cover bolt (crankcase/ PTO cover) 24 24-26 24-26
Cylinder head bolt 36 40-42 48
Flywheel nut 75-80 96-102 96-102
Flange bolt for value cover (head cover) 7 12-13 12-13
