LCT 208cc - 414 cc Summer Engine Dimensions

Rev:072409 Copyright © 2009 Liquid Combustion Technology, LLC LCT Engine Service Manual: 208cc, 291cc & 414cc 15
414cc Summer Engine Dimensions
*Drawings do not accurately represent actual engine appearance.
22.5
29
17
R13
R7
132
ø12
2-ø10.5
90
400
485
14
106
432
133±0.03
