Portable Plasma Torch Height Controller Manual (F1620)
5
14） Collision signal feedback
THC can make numerical control system receive collision feedback signal, it
can avoid that torch is working after collision have happened. THC make CNC
receive collision feedback signal after collision happened several times, it can keep
coherent torch.
1.4 Technique parameter
¾ Work voltage：Rated DC 24V （The scope is 21.6VDC-26.4VDC）。
¾ Lifting motor：DC 24V.
¾ Motor drive：PWM.
¾ Output current：0A-3A (the electric current that motor can input is 5A).
¾ Load capacity：100W.
¾ Working temperature：0 ~50 .℃℃
¾ IHS：proximity switch of IHS.
Torch retaining cap of IHS.
¾ Voltage divide ratio：100:1
¾ The precision of arc voltage sampling：0.2V
¾ The precision of arc voltage adjust：1V
¾ The speed of lifting：It determines by highest speed of lifting.
¾ Setting scope of arc voltage：30V~600V, it can change by panel spin button.
¾ The biggest torch following speed：It determines by highest speed of lifting.
¾ Overload protect：auto overload、overheating、lack of voltage protect，making
power source connect adversely to protect itself.
1.5 THC Installation size
¾ THC installation size：width 271mm
，
depth 190mm
（
it can not contain line and
port in back)
，
height 70mm
。
¾ THC installation screw of IHS：
