Portable Plasma Torch Height Controller Manual (F1620)
11
into the parameter modification model. Then the red LED start flicker, it means this
parameter is waiting for changing. Pressing the button named 【 +】 /【 -】 can
increase/decrease parameter, the value which user change will display in the
parameter. After parameter have changed, user can save it by pressing the button
named【OK】and cancel it by pressing the button named【MENU】.
If user save it by pressing the 【OK】button, the red LED will stop flicker and
display the value which user have change. If the parameter have be changed and user
cancel it by pressing the 【MENU】 button, the red led will stop flicker and display the
value which the parameter is not changed。
THC have“Pxx”“Hxx”“Lxx” three submenu.With the addition of non-menu
model, it have four condition. When the button named【MENU】is pressed, THC can
switch in four condition circularly. Warning: During the non-menu model, if THC
is testing or auto height control is working, THC will not enter into the menu
model and change parameter. Similaryly, if THC have entered into menu model,
it will not start test and auto height control. After the parameter have changed,
user must be remember to exit menu model in time.
“Pxx”submenu contain 21 parameters, they are“P00”~“P20”and contain sundry
quantification parameter. The sundry parameter can change in this submenu.
“Hxx”submenu contain 9 parameters, they are“H01”~“H09”. It is used to check
input signal is high level or low level. The sundry parameter can not change in this
submenu. Warning : During torch start to work, pressing the button named
【MENU】can look up the level condition of input port.
“Lxx”submenu contain 9 parameters, they are“L01”~“L09”. It can be set the
input signal as high level effective or low level effective. The sundry parameter can
change in this submenu.
“Pxx”submenu listing
Para
meter
numb
er

Settin
g
scope
step
and
lengt
h
adju
st
Initial
para
meter
Yell
ow
LED
Red
LED
Remark
P00
0-1 1 1 P00 1 Recovering factory parameter/
amending parameter interval
P01
0-50 1 50 P01 50 Setting manual lift speed of torch, the
minimum speed is 0, the maximum
speed is 50. CNC_THC_UP also use
this speed.
