LS600 Installation and Operation Guide 15
www.leadsolarenergy.com
2. Notice that the AC output neutral is not bonded to ground inside LeadSolar microinverter.
3. For systems with PV racking that is already grounded, securely attach the PV module and microinverter to
the grounded PV racking by using washers and tightening the grounding clamp screw.
Never start system operation before finishing system grounding. The ground fault
detection device (GFDI) inside the microinverter may be tripped if the system is
not securely grounded.
Step 7:
Completer the Installation Map
We need series numbers of installed microinverters for registering in our service later..
The Installation Map is a diagrammatic representation of the physical location of each microinverter in you
PV installation. The virtual array in our web APP is created from the map you created. You can create a blank
according to your previous system design before placing the microinveters to the arrays.
Each microinveter has a removable serial number label located on the top of our microinverters,.when installing
the microinverters, remove the serial number labels located and place in the correct order on your drawing of
the system. Remember to keep a copy of the installation for your records.
You are not done yet! Complete the Operation Guide section to begin use
properly. It is important to record the series number of the microinverters and
communication gateways for adding these devices in our database.
Step 8: Install the Link nearby the AC Main
Link is an integral component of the LeadSolar Energy Microinverter system. Its functions as a
communication gateway and monitors the microinverters that are connected to the PV modulesl. The Link
collects energy and performace data from the microinverters via on-site AC power lines.
LeadSolar recommends that the Link be placed as close to the AC mains as possible. This ensures that
the Link receives the strongest possible signal from each microinverter. The Link must be indoors and can be
placed on a table or mounted on the wall. The AC outlet that the Link plugged in must be close to the AC mains
and keep the same phase with the point that PV system tied in.
Step 9: Connect the PC Modules
Connect the each microinverter DC input terminals to the adjacent two PV modules output terminals
through the Quick Connect cable. Check your work to make sure all the microinverters in the system are
securely connected to the PV modules.
