LS600 Installation and Operation Guide 8
www.leadsolarenergy.com
Installation
Follow the instructions in this section to install LeadSolar LS600 Microinverters.
Only qualified personnel should connect the LeadSolar Microinverter to the utility
grid. Installation includes risk of electric shock. PV modules connected to
LeadSolar Mircroinverters must be grounded before installation.
3.1 Compatibility & Capacity
The LS600 model is compatible with both 60-cell and 72-cell PV modules. For more information, see Technical
Data.
The LS600 should only be connected to the grid type listed below:
Electrical Compatibility
Model Number Compatible PV Module Type PV Module Connector Type
LS600 60-cell or 72-cell PV Module MC-4 Type 2 Locking or Amphenol H4 Locking
Maximum # Microinverters per 18 amp AC Branch Circuit
Grid Voltage/Type Maximum Allowed LS600 inverters
Single Phase 230V 7
3.2 Packaging
Included in a LeadSolar Microinverter System package are:
Object description Quantity
1. Microinverter 1
2. Grounding terminal 1 set
3. Installation manual 1
4. Warranty terms and conditions 1
