LeapFrog LF925HD - Overview; Parent Unit Components; Baby Unit Components

1
Link LED light
2
Battery LED light
3 3-level sound indicator light
4
Night Mode quick set key
• Select black-and-white or
color night vision viewing
mode.
• Adjust night light brightness.
5
Arrow Keys
6
Menu / Select
7
Talk
/
Return
8 Microphone
9
Volume
• View the volume
adjustment bar.
10
Zoom / Help
11
Power / LCD Off
12 Antenna
13 Power jack
14 RESET
15 Stand
Overview
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
7
8
9
10
4
6
3
5
2
11
1
7
8
9
10
4
6
3
5
2
11
12
13
1
7
8
9
10
6
11
12
13
1 Light sensor
2 Camera
3 Infrared LEDs
4 Microphone
5 Night light
6
Night light control key
• Tap to turn the night light on or off
• Tap and hold to adjust night light
brightness level.
7 POWER LED Light
8 On / Off switch
9 Antenna
10 Power jack
11 Speaker
12 Wall mount holes
13 PAIR key
• The Parent unit and Baby Unit(s) provided
are already paired.
Baby Unit
Parent unit
