1-4
FOR TRAINING PURPOSES ONLY
LEARJET 20 SERIES PILOT TRAINING MANUAL
FlightSafety
international
A
B
C
MODELS
23 AND 24
MODEL
25
A 27 FT 10 IN. 31 FT 3 IN.
B 34 FT 4 IN. 37 FT 6 IN.
C 31 FT 11 IN. 35 FT 1 IN.
NOTE:
THE VALUES SHOWN REFLECT NORMAL
NOSEWHEEL STEERING. SHORTER TURNS CAN
BE EFFECTED WITH THE USE OF A TOW BAR.
Figure 1-3. Airplane Turning Radii
