18
ENGLISH
M) General diagram
Fuse
24Vac
F
2
4
3
2
1
J2
Power regulator
card
P1 P2
Pause Work Codes
JP3 JP2 JP1
P3
F
1
Fuse
230Vac 5A
DL2
Power supply
Programming
DL1
GROUND
YELLOW-GREEN
CLOSE
OPEN
CAPACITOR
BLINKER
PHOTO NC
AERIAL
CLOSING LIMIT
SWITCH NC
OPENING LIMIT
SWITCH NC
COMMON
START NO
COMMON
OUTPUT
24 Vac
J5
J4
J1
J3
F
N
230 Vac
1 2 3 4 5
1 2 3 4 5 6 7 8
1 2 1 2
M1
COM
