26
FRANCAIS
M) Schéma général
Fusible
24Vac 2A
F
2
4
3
2
1
J2
Régulateur de
puissance
P1 P2
Pause
Travail Code
JP3 JP2 JP1
P3
F
1
Fusible
230Vac 5A
DL2
Alimentation
programmation
DL1
JAUNE-VERT
CONDENSATEUR
CLIGNOTANT
PHOTO NC
FC FERMETURE
NC
FC OUVERTURE
NC
START NO
COMMUNE
J5
J4
J1
J3
F
N
230 Vac
TERRE
1 2 3 4 5 1 2 3 4 5 6 7 8
ANTENNE
COMMUNE
SORTIE
24 Vac
1 2 1 2
M1
COM
FE
OU
