p100 Leckey BeMe User Manual
SECTION 18.2:
ADJUSTING SEAT
DEPTH AND LEG ANGLE
ABDUCTION AND
ADDUCTION ON SPLIT
SEAT
SECTION 18.3:
ADJUSTING
SEAT DEPTH ON
CONTOURED SEAT
To adjust the seat depth and leg angle on the
split seat, loosen the left and right bolts
,
on the underside of the seat base and move
each seat leg component separately to a
suitable position. The seat leg components
can be moved forward, backwards and to 15
degrees abduction/adduction. Tighten both
bolts to secure in place.
To adjust the seat depth of the contoured
seat, first remove the contoured cushion
assembly
, from the seat base, and remove
the covers and foam. Loosen the bolts
, at
either side of the plate and slide forward and
backwards to the desired position. Tighten
the bolts to secure in place.
