p40 Leckey BeMe User Manual
Feature Parameter Value
Make and Model Actuator LINAK 281209-01
Battery LINAK BA18021-00
Hand Controller LINAK HB41000-00004
Battery Charger LINAK Battery Charger CH01.
Only use this supplied battery
charger
Seat lift operation Duty Cycle Maximum 10% Or 2 min
continuous followed by 18 min
not in use
Actuator Force 3500N push, 2000N pull
Actuator operating speed 4.7mm/sec at full load
Noise level 48 dB(A)
Environmental IP Rating IP51 (not waterproof, clean with a
damp cloth only)
Operation +5 deg C to 40 deg C
20% to 80% RH, non-condensing
Transport and Storage -10 deg C to 50 deg C
20% to 80% RH, non-condensing
Allow 2 hours for the device to
come to room temperature after
removing from storage
Height above sea level Max 3000m
Electrical Actuator operating voltage 24V
Actuator operating current Maximum 3.9A
Charger input 100 – 240 Vac, 50/60 Hz
Charger output 27.6 Vdc ± 2%
Charging current Max 500 mA
Charging indication on
charger
Green LED – Mains power
Yellow LED – Charging, turns
to Green when battery fully
charged
Certification EMC IEC60601-1-2:2014 for home use
environment
Electrical Safety IEC60601-1:2005/A1:2012
TECHNICAL SPECIFICATIONS:
