p48 Leckey BeMe User Manual
SECTION 16.5:
ATTACHING AND
DETACHING
BASIC, SPLIT AND
CONTOURED SEAT
HARDWARE
The front seat plate of the basic, split and
contoured seats secures to the receivers on
the seat base. First locate the downward
pointing prongs at the front of the seat plate,
, and the upper slot in the receivers , at
the end of the femoral bars. Slot the prongs
into the left and right receivers, ensuring
the two holes on each side align. It may be
required to adjust the position of the femoral
bar to allow for the receivers to be positions
correctly. To do this, loosen the bolt
, on
the underside of the seat base, and move to a
suitable position. Once the seat plate prongs
are located, securely tighten using the 4 bolts,
, and the Allen key.
To detach the seat plate, reverse the process.
