Leckey BeMe - Page 53

Leckey BeMe User Manual p53
SECTION 16.10:
ATTACHING AND
DETACHING SANDALS
Insert the required attachment bolt , along
with the retention plate
. Place a rubber lid,
, on both the top and bottom of the sandal.
Fasten using the four screws
, provided.
To remove or replace the attachment bolt,
reverse this process.
To detach the attachment bolts on sandals,
reverse the process.
To attach the sandal
, place it on the
footplate
, so that the attachment bolt,
, goes through the slot in the footplate.
To secure, place the rubber washer, metal
washer, and knob
, onto the attachment
bolt on the underside of the footplate, and
tighten.
To detach the sandals, reverse the process.
