Leckey BeMe User Manual p77
To attach the dynamic backrest, the static
backrest plate must first be removed. Remove
the two top and back bolts
, and remove
the cover moulding. Remove the central bolt,
, and the static backrest plate .
SECTION 16.35:
ATTACHING AND
DETACHING DYNAMIC
BACK
Use caution when assembling
and fitting the dynamic backrest
as there is a minor risk of finger
nipping.
Align the holes of the aluminium bracket of
the dynamic back assembly
, with the holes
on the seat base. Secure using the five bolts
provided
E
.
Rotate the dynamic back assembly around
so that the holes in the aluminium block align,
and secure using the two bolts provided
F
.
E
F
