LECTRO 36VDC - Page 31

31
3.0 Power Supply, continued
745-573-B0-001 REV. A
3.2 Battery Installation and Connection, continued
-
+
+
-
+
-
+
-
-
+
UPPER SHELF
LOWER SHELF
CABINET FRONT
RED
BLACK
OPTIONAL XM STYLE
TEMPERATURE PROBE
-
Negative (Black)
Middle (Orange)
Positive (Red)
Middle, Longer
lead (Orange)
BATTERY SENSE INPUT
TEMP PROBE INPUT
+
Red and Black
Anderson
Connector
For Level 3 wiring, refer to manual P/N 040-0080-1501
Fig. 3-10, 36V Battery Sensing and Temperature Probe Connection – Parallel Strings
