32
3.0 Power Supply, continued
745-573-B0-001 REV. A
3.2 Battery Installation and Connection, continued
-
+
- -
+
-
UPPER SHELF
CABINET FRONT
RED
BLACK
OPTIONAL XM STYLE
TEMPERATURE PROBE
Negative (Black)
Middle (Orange)
Positive (Red)
If unused, tuck connector out of the way
BATTERY INPUT
+
+
TEMP PROBE INPUT
Gray Anderson
Connector
Middle Longer (Orange)
For Level 3 wiring, refer to manual P/N 040-0080-1501
Fig. 3-11, Battery Sensing and Temperature Probe Connection – Single String
