LeeLen V31 - Default Chapter; Contents of the Package; Main Technical Parameters; Product Description

Contents
1
1. Contents of the Package
EH2W-IS-V31
Wire(2.54)Wire(2.0)
Bracket Screw(M4*20PMC)
Indoor Station
×1
×2
×1
×2
2. Product Description
2
1
3
4
5
6
1. Touch Screen
2. Microphone
3. Doorbell Port
4. Power Supply Port
5. 2-wire Communication Port
6. Loudspeaker
2.1 Indoor Station
Indoor Station
LCD screen 1024×600
Working voltage 24V DC
Max power consumption 3.5W
Standby power consumption 1.5W
Ingress protection IP30
Working temperature -20℃~ +55℃
External dimensions 200mm × 140mm ×18mm
2.2 Main Technical Parameters
(W×H×D)
1. Contents of the Package .............................................................................................................................................
2. Product Description......................................................................................................................................................
2.1 Indoor Station..........................................................................................................................................................
2.2 Main Technical Parameters ...................................................................................................................................
3. System Installation........................................................................................................................................................
3.1 Wires and Distance.................................................................................................................................................
3.2 Connection Diagram...............................................................................................................................................
3.2.1 One to One Kit...............................................................................................................................................
3.2.2 Multi to Multi Kit..............................................................................................................................................
3.3 Installation..............................................................................................................................................................
4. Parameter Settings.......................................................................................................................................................
4.1 Enter Setting Function.............................................................................................................................................
4.2 System Parameter Settings ....................................................................................................................................
4.3 Indoor Station Parameter Settings............................................................................................................................
5. Description of the System Functions..............................................................................................................................
5.1 System Functions...................................................................................................................................................
5.2 Call, Intercom and Leave Message..........................................................................................................................
5.3 Monitor.....................................................................................................................................................................
5.4 Privacy.....................................................................................................................................................................
5.5 Screen Lock.............................................................................................................................................................
5.6 Record Views..........................................................................................................................................................
5.7 Anti-Dismantle Alarm...............................................................................................................................................
