26
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
p214
Minimum Alarm 0.0 P204 P205 Use with P140, P142 = 18...23
P215
Maximum Alarm 0.0 P204 P205
P231
Preset PID
Setpoint #1
0.0 P204 P205 TB-13A activated; P121 = 3 and
P200 = 1 or 2
P232
Preset PID
Setpoint #2
0.0 P204 P205 TB-13B activated; P122 = 3 and
P200 = 1 or 2
P233
Preset PID
Setpoint #3
0.0 P204 P205 TB-13C activated; P123 = 3 and
P200 = 1 or 2
P240
Sleep Threshold 0.0 0.0 {Hz} 500.0 • If drive speed < P240 for longer than
P241, output frequency = 0.0 Hz;
drive display = SLP
• P240 = 0.0: Sleep mode is disabled.
• P200 = 0…2: Drive will start again
when speed command is above
P240
• P242 > 0.0: Drive will restart when
the PID feedback differs from the
setpoint by more than the value
of P242 or when the PID loop
requires a speed above P240.
P241
Sleep Delay 30.0 0.0 {s} 300.0
P242
Sleep Bandwidth 0.0 0.0 B
max
Where: B
max
= |(P205 - P204)|
