Custom mode: the user sets the output data of each channel when the RC is failsafe, to
ensure that the output of the flightmode channel(CH5/CH6) can make the FC switch to RTH
when the RC is failsafe.
PPM/IBUS/CRSF: it is recommended to use cut mode or custom mode.
SBUS: the FC can automatic recognition as failsafe,and switch to RTH.
* If the SBUS of your RC is not a standard protocol, it may cause the failure to recognize failsafe.
* GPS must be connected, otherwise the RTH cannot be used; after setting failsafe, you can turn off the
RC for testing on the ground.
➢ Use HD VTX
According to the type of your VTX,
<Settings & Display>
-
<HD VTX selection>
, then
refer to
<Using DJI V2>
and
<Using DJI O3/AVATAR>.
If you need to adjust the OSD
position,refer to
<Settings & Display>
-
<Aircraft model settings and OSD position
adjustment>
, adjust the DIP switch to the appropriate position, after adjusting the OSD
position, set the DIP switch correctly according to your model.
➢ Unlock the FC
Refer to
<Unlock the FC>.
➢ Throttle differential for dual motors
Refer to
<Servos Connection>
. After completing
<Unlock the FC>
, it is recommended
to push the throttle to more than 50%, dial the yaw joystick, and determine whether the
throttle differential direction is correct. If not, just swap the positions of the two ESC wires.
➢ Calibrate ESC
Step1：Switch to MANUAL mode, push throttle to the highest position;
Step2：Power on;
Step3：Follow the ESC user manual, wait for the correct ESC beep, and then pull the throttle
to the lowest position;
Step4：If there are two motors, the two ESCs need to be calibrated separately.
