MODEL SERIES SPECIFIC FEATURES

UTILITY 16 WIDEBODY SHOWN

SINGLE CONSOLE 151 ANGLER SHOWN

Battery

Battery storage area

Navigation Lights

Bilge Pump

Drain Plug

Drain Plug

Livewell

Livewell

Fuel Tank storage area

Livewell Drain

Livewell Drain

Fuel Tank

Fish/Depth Finder

Front Storage

Switches:

Circuit Breakers

Navigational Lights

Bilge Pump

Livewell
