LEGRAND Easy Kit Connected User Manual

Easy Kit Connected
2
Telephone twisted pair
Verdrillte Telefonadern
573999 (SCS Legrand)
2 x 0.28 mm
2
(0.13 Ohm/m) 2 x 0.5 mm
2
(0.04 Ohm/m)
0 – 80 m 0 – 100 m
• Cables and distances (mm
2
)
• Distance between the last internal unit and the last entrance panel
• rot: +
• red: +
•
Max. length of the covered cable: 20m
• Ca ble loop impedance: 0.08/m
• Maximale Kabellänge: 20m
• Kabel-Schleifenimpedanz: 0.08/m
-
• schwarz: -
• black: -
• Kabel und Leitungslängen (mm
2
)
• Abstand zwischen der letzten Hausstation und der letzten Türstation
• rot: +
• red: +
• schwarz: -
• black: -
