Keor MOD
Installation and maintenance manual
95
Output electrical characteristics (normal mode)
Keor
MOD
25
Keor
MOD
50
Keor
MOD
75
Keor
MOD
100
Keor
MOD
125
Keor
MOD
150
Keor
MOD
175
Keor
MOD
200
Keor
MOD
225
Keor
MOD
250
Maximum output
current (A)
36 72 108 144 180 216 252 288 324 360
Output voltage
(V)
380/400/415 ± 1%
Output frequency
(Hz)
50 / 60
(selectable by the user)
Range of the output
frequency
If synchronized with the bypass frequency: adjustable range from ±1% to ±14%
If not synchronized (free run): ± 0.1 Hz
Crest factor admitted
on the output current
3:1
Total harmonic distortion
of the output voltage
THDv < 0.5% (at full linear load)
THDv < 1% (at full non-linear load)
Eciency in Normal
Mode
up to 96.5%
Eciency in Eco Mode 99%
Overload capacity
125% for 10 minutes without automatic bypass intervention
150% for 60 seconds without automatic bypass intervention
Output electrical characteristics (battery mode)
Keor
MOD
25
Keor
MOD
50
Keor
MOD
75
Keor
MOD
100
Keor
MOD
125
Keor
MOD
150
Keor
MOD
175
Keor
MOD
200
Keor
MOD
225
Keor
MOD
250
Output voltage
(V)
380/400/415 ± 1%
Output frequency
(Hz)
50 / 60 Hz ± 1%
Total harmonic distortion
of the output voltage
THDv < 0.5% (at full linear load)
THDv < 2.5% (at full non-linear load)
Overload capacity 115% for 10 minutes
Shortcircuit
Icc = 3 In for 50 ms
Icc = 1.45 In for 1 sec
