3
Installation and maintenance manual
Keor MOD
1 Introduction 5
1.1 Purpose of the manual 5
1.2 Symbols in the manual 5
1.3 Where and how to keep the manual 5
1.4 Update of the manual 6
1.5 Manufacturer’s liability and guarantee 6
1.5.1 Guarantee terms 6
1.5.2 Extension of the guarantee and maintenance contracts 7
1.6 Copyright 7
2. Regulatory and safety requirements 8
2.1 General notes 8
2.2 Denitions of “Skilled Technician” and “Operator” 8
2.2.1 Skilled Technician 8
2.2.2 Operator 8
2.3 Personal Protective Equipment 8
2.4 Hazard signs in the workplace 9
2.5 Signs on the equipment 9
2.6 General warnings 10
2.7 How to proceed in an emergency 11
2.7.1 First-aid procedures 11
2.7.2 Fire procedures 11
3. Transportation and placement 12
3.1 Visual check 12
3.2 Equipment check 12
3.3 Transportation 13
3.4 Unpacking 14
3.5 Placement 15
4. Installation 17
4.1 Safety regulations 17
4.2 Electrical connections 17
4.2.1 Protective devices 18
4.2.2 Disassembly of the distribution panel 18
4.2.3 Earthing connection 23
4.2.4 Cable fastening 25
4.2.5 Backfeed protection 34
4.2.6 Input cables installation 35
4.2.7 Bypass cables installation 41
4.2.8 Output cables installation 45
4.2.9 Battery cables installation 49
4.3 Power modules installation 58
4.4 Battery drawers installation 60
4.5 SSS interface 66
4.5.1 Emergency Power O (EPO) 67
