LEGRAND KEOR T EVO 10-60 KVA User Manual

Important Notices!
Thank you for choosing LEGRAND UPS System to supply your Critical Application.
This manual contains important information about commissioning, usage and technical properties of the
UPS. It also contains safety information for operator and instructions to secure your critical load. Applying
the recommendation detailed in this manual is necessary to use UPS safely and correctly.
The manufacturer reserves the rights to change the technical specications
and design without notice.
LEGRAND reserves the rights to change the information in this document
without notice. Refer to http://ups.legrand.com/ web site to dowload last
release and translations.
Units that are labelled with a CE mark comply with the Standard: EN 62040-1 and EN 62040-2.
Read the manual completely before working on this equipment!
Keep this manual in UPS’s front cover’s pocket for easy consultation!
Reproduction, adaptation, or translation of this manual is prohibited without prior
written permission of LEGRAND Company, except as allowed under the copyright laws.
18
18
6. Installation
When the UPS is delivered, examine the packaging and product carefully to see if any damage occurred
during transport.
If either possible or ascertained damage is found report it immediately to:
• the carrier;
• LEGRAND Technical Assistance Centre.
Make sure that the unit received corresponds to the material specied on the delivery document. The
UPS KEOR T EVO packaging protects the equipment against mechanical and environmental damages. For
greater protection it is also wrapped in a transparent lm.
Check if the following are provided with the equipment
• UPS
• Installation & Operating Manual
• Key for door
• Battery fuses (three pieces)
• Plinths
Before the installation, please check if your UPS is customized following your
special requirements (if any).
6.1. Models and Dimensions
UPS Type Dimension (HxWxD) (mm) Net Weight (Kg) Internal Batteries Type
UPS KEOR T EVO 10 KVA 1345H P0 1345 x 400 x 800 122 No battery
UPS KEOR T EVO 10 KVA 1345H P1 1345 x 400 x 800 261 60 blocks 7 AH
UPS KEOR T EVO 10 KVA 1345H P2 1345 x 400 x 800 283 60 blocks 9 AH
UPS KEOR T EVO 10 KVA 1650H P3 1650 x 400 x 800 426 120 blocks 7 AH
UPS KEOR T EVO 15 KVA 1345H P0 1345 x 400 x 800 127 No battery
UPS KEOR T EVO 15 KVA 1345H P1 1345 x 400 x 800 268 60 blocks 7AH
UPS KEOR T EVO 15 KVA 1345H P2 1345 x 400 x 800 288 60 blocks 9 AH
UPS KEOR T EVO 15 KVA 1650H P3 1650 x 400 x 800 431 120 blocks 7 AH
UPS KEOR T EVO 20 KVA 1345H P0 1345 x 400 x 800 134 No battery
UPS KEOR T EVO 20 KVA 1345H P1 1345 x 400 x 800 275 60 blocks 7AH
UPS KEOR T EVO 20 KVA 1345H P2 1345 x 400 x 800 296 60 blocks 9 AH
UPS KEOR T EVO 20 KVA 1650H P3 1650 x 400 x 800 477 120 blocks 9 AH
UPS KEOR T EVO 30 KVA 1345H P0 1345 x 400 x 800 141 No battery
UPS KEOR T EVO 30 KVA 1345H P1 1345 x 400 x 800 302 60 blocks 9 AH
UPS KEOR T EVO 30 KVA 1650H P2 1650 x 400 x 800 441 120 blocks 7 AH
UPS KEOR T EVO 30 KVA 1650H P3 1650 x 400 x 800 484 120 blocks 9 AH
UPS KEOR T EVO 40 KVA 1650H P0 1650 x 600 x 900 238 No battery
UPS KEOR T EVO 40 KVA 1650H P1 1650 x 600 x 900 538 120 blocks 7 AH
UPS KEOR T EVO 40 KVA 1650H P2 1650 x 600 x 900 573 120 blocks 9 AH
UPS KEOR T EVO 40 KVA 1650H P3 1650 x 600 x 900 740 180 blocks 9 AH
UPS KEOR T EVO 60 KVA 1650H P0 1650 x 600 x 900 258 No battery
UPS KEOR T EVO 60 KVA 1650H P1 1650 x 600 x 900 590 120 blocks 9 AH
UPS KEOR T EVO 60 KVA 1650H P2 1650 x 600 x 900 755 180 blocks 9 AH
Table.3
