KEOR T EVO
Installation & Operation Manual
Bypass voltage (Ph-N) and frequency information of
each phase are displayed. If the MAINS and AUX Supply
are connected in COMMON, Rectier and Bypass values
will be the same.
Rectier voltage (Ph-N), current and frequency
information of each phase are displayed. If the MAINS
and AUX Supply are connected in COMMON, Rectier
and Bypass values will be the same.
When the Password Screen appears, enter 1111,
touch ENTER to conrm.
7.2.3. Settings Menu
This menu is the section where all the settings related to UPS usage customization can be done.
User Password must be entered to make changes in this section.
User Password: 1111 (the password cannot be changed)
