Lehmannaudio Decade - Troubleshooting

Technical specifications
MM MC
Sensitivity for output level
775 mV/ 0 dB
(with activated high gain switch)
3.8 mV/1 kHz 0.38 mV/1 kHz
Gain 1 kHz 46 dB 66 dB
Maximum input level 45 mV 4.5 mV
Signal to noise ratio
(RMS unweighted)
78 dB 69 dB
Gain 36 dB, 46 dB, 56 dB, 66 dB
Channel separation > 80 dB at 10 kHz
Input impedance 47 kohms, 1 kohm, 100 ohms
≠
1 x custom load
Output impedance 5 ohms
Input capacitance 47 pF to 1,370 pF
Channel mismatch typ. 0.5 dB
Bass filter 50 Hz, 6 dB/oct.
Power consumption app. 13 VA
Mains voltage
≠
Europe: 240 V AC
≠
USA/Canada/Mexico/Taiwan: 120 V AC
Fuse
≠
Europe: 250 mA Slow
≠
USA/Canada/Mexico/Taiwan: 500 mA
Slow
Outer dimensions W x D x H
≠
Audio section: 110 mm x 280 mm x 50 mm
≠
PWX II power supply:
110 mm x 280 mm x 50 mm
Weight
≠
Audio section: 0.87 kg netto
≠
PWX II power supply: 1.56 kg netto
Troubleshooting
Fault Cause Solution
LED indicator is
not lit.
The mains cable is not
plugged in at the power
outlet.
Insert the mains cable into the
power outlet.
The power supply is not
connected with the device.
Connect the power supply with
the device.
No signal. The mains cable is not
plugged in at the power
outlet.
Insert the mains cable into the
power outlet.
The power supply is not
connected with the device.
Connect the power supply with
the device.
Input and output are not
wired correctly on the
Decade.
Check if the cables coming from
the turntable are connected to
the input and also if those going
out to the amp are connected
to the output of the Decade.
Reconnect them correctly if
necessary.
A wrong input channel
has been selected on the
following amplifier.
Select the appropriate input
channel.
