Group 7 Data/Programming Page 99
Release R2.0 LEIBINGER JET3
Batch Job (11)
Up to 1023 print jobs can be listed in an <Batch Job> job list (11). A job is added
either with the <Import Job> button (5) or with the respective option of the <Edit>
drop-down menu of the menu bar (2). Both will open an <Open file> dialog box. A
print job will be added below the current cursor position. With the <Delete Job>
button (6) the currently marked job will be removed from the list. The job list shows
the <No.> (14), the number of <Repetitions> (13) and the name of the <Job>
(4). The number of <Repetitions> (13) for a selected print job is defined and
indicated through a display field with Numeric keypad and/or arrow keys (12). The
print jobs plus optional repetitions will be printed in the order of the job list display
(8). The job list (8) can either be processed in a loop (16) or the print-out can be
stopped after the last job on the list was printed (15).
Job organisator (17)
Up to 16 print jobs can be listed in a <Job organisator> list (17). A job is added
either with the <Import Job> button (5) or the respective option of the <Edit>
drop-down menu of the menu bar (2). Both will open an <Open file> dialog box. A
print job will be added below the current cursor position. With the <Delete Job>
(6) button the currently marked job will be removed from the list. The job list shows
the <No.> (13), the <Distance> (19) between the reference point and the print
job and the name of the <Job> (4). The reference point is defined by the
<PrintGo> signal. The <Distance> for a selected print job is defined and indicated
through a display field with a Numeric keypad and/or arrow keys (18). The print jobs
will be printed in the order of the job list (8) taking into account the <Distance>
settings (18).
All numbers in the following description refer to figure 39
Menu bar of the job list creator (1)
In the following all dialog boxes related to the menu bar of the job list creator are
described. Changes made in these dialog boxes may either be confirmed with the
<OK> button (18) or discarded with the <Cancel> button (19).
Joblist (1a)
The drop-down menu <Joblist> (1a) offers options for file handling and for exiting
the dialog box.
<Save Joblist> (2)
Will save the file under the current file name. After
saving the dialog box will close.
<Save Joblist as> (3)
Opens a <Save file as> dialog box (6) and offers
the option to save the file under a different name.
After saving the dialog box will close.
<Load joblist to print> (4)
Should not be used while creating a new job list.
This function should only be used during job list
editing.
<Close joblist creator> (5)
Closes the dialog box. If the current job was not
already saved a message box will ask for saving.
