Leibinger Jet 3 - Page 158

Group 7 Data/Programming Page 156
Release R2.0 LEIBINGER JET3
Figure 72
Jet adjustment (Step 1)
1 – TFT-Touch-Display
6 – Option <Printhead>
2 – Message <Initialization>
7 – Direct button (Icon) <Service>
3 – Main menu
8 – Tab <Printhead>
4 – Message <Bleeding>
9 – Tab <Printhead>
5 – Button <ServiceFunctions>
10 – Button <Ink-Flow-Sensor active>
5
6
10
5
7
8
or
Monitoring turned off
1
3
2
4
9
Monitoring turned on
