7.5.5.4 View settings
With the button <View> you can select the display tools of the editor.
Figure 95
Graphic editor (Display tools)
1 – Button <View>
4 – Display tool <Show grid>
2 – Display tool <Zoom In>
5 – Display tool <Settings>
3 – Display tool <Zoom Out>
Pos.
Display tool
Function
2.
Zoom In
Enlarges the display in the input field <Graphic>.
3.
Zoom Out
Reduces the display in the input field <Graphic>.
4.
Show grid
Turns on or off the grid display. If the grid is turned on,
it is displayed with a checkmark on the button.
5.
Settings
Enables the settings of the edit size (width and height
of the drawing area) as well the settings of the grid size.
INFORMATION
You will find further information regarding the function of the several
display tools also in the chapter Carry out settings of the graphic editor!
