Release R2.0 LEIBINGER JET3
7.5.5.7 Graphic editor settings
With the display tools you can change the settings of the editor. The following
functions are available:
 Enlarge and reduce display size (Zoom in/out)
 Show grid
 Settings
With the option <Settings> you can set the editor size (width and height of the
drawing area) as well as the grid size.
Proceeding:
 Press the button <View> (1) and the option <Settings> (2).
 The window <Editor Settings> (3) is faded in.
 With the Arrow keys (4) you can increase or reduce the values of the editor size
and the grid size by one step.
alternatively
 Click in the appropriate display field (5) of the value which you would like to
change. A Numeric keypad opens for input Now enter the requested value.
INFORMATION
You will find further information regarding the working with keyboard
in the chapter Keyboard!
 The button <OK> (6) closes the window.
Note: Irrespectively of the set grid size points are always created in the grid size 1x1
and line- and circle elements in the grid size 1.
INFORMATION
You will find further information regarding the further display tools in
the chapter Display tools!
