Group 7 Data/Programming Page 209
Release R2.0 LEIBINGER JET3
7.5.7.4 Delete jobs
INFORMATION
A job can only be deleted in the explorer!
(Example: The job „temp“ should be deleted in the internal memory.)
Figure 105
Explorer (Delete job)
1 – Selection window <Harddisc>
5 – Button <Cancel>
2 – Selected job
6 – Button <No>
3 – Tool <delete>
7 – Button <Yes>
4 – Message <Delete file>
8 – Button <Yes, All>
Proceeding:
 Click on the display area of the selection window <Harddisc> (1) to activate it.
The border of the window is now displayed turquoise.
 Select the job with the designation“temp.job“ (2) by clicking on the checkbox or
the designation. The selection is displayed with a  in the checkbox.
8
5
4
2
3
6
7
1
2
