Group 7 Data/Programming Page 210
Release R2.0 LEIBINGER JET3
 Press the icon of the tool <delete> (3).
 The message <Delete file> (4) is faded in.
 Press the button <Yes> (7) to delete the selected job or press the button <No>
(7) or the button <Cancel> (5) to abort the process.
7.5.8 Touch-Calibration
The function provides a calibration of the TFT-Touch-Display. The device is delivered
with a calibrated touch display.
Figure 106
Touch-calibration
1 – Button <Extra>
5 – Message <Setting calculation>
2 – Option <Touch Calibration>
6 – Message <Touch calibration successfully>
3 – Calibration window
7 – Button <OK>
4 – Calibration point
1
2
3
4
7
6
5
4
