Group 7 Data/Programming Page 211
Release R2.0 LEIBINGER JET3
ATTENTION
To avoid faulty operation you have to carry out the calibration carefully!
Proceeding:
 Press the button <Extra> (1) and the option <Touch Calibration> (2).
 The calibration window (3) opens.
 Now press carefully on the middle of the calibration point (4). Repeat the process
as long as the calibration point moves on the display.
 If the settings are calculated an accordring message (5) is displayed on the upper
area of the calibration window. Now press any point on the Touch Display to
accept the settings.
 The message <Touch calibration successfully> (6) is faded in.
 Finally press the button <OK> (7) to finish the process.
7.6 Help
With the button <Help> (1) in the main menu bar you can call up the options <Info>
(2) and <LoginLog> (3).
Figure 107
Launch help
1 – Button <Help>
2 – Option <Info>
1
2
