Group 8 Job editor Page 270
Release R2.0 LEIBINGER JET3
GS1-ECC200 rectangle
 Same specifications as the GS-1 ECC200 square but:
 rectangular with sizes from 8×18 to 16×48 (even values only)
PPN-ECC200 square
 The PPN Code is the machine-readable identification of retail packs with the
Pharmacy Product Number.
 The ECC200 data matrix code is used for the encoding of the information.
PPN-ECC200 rectangle
 Same specifications as the PPN ECC200 square but:
 rectangular with sizes from 8×18 to 16×48 (even values only)
QR-Code
 QR code (Quick Response Code) is the trademark of a type of matrix barcode.
 The amount of data that can be stored in the QR code symbol depends on the
data type (mode, or character set), version (1, …, 40, indicating the overall
dimensions of the symbol), and error correction level.
IMPORTANT
 The JET3 job editor offers the possibility to add the content of each
bar code type as plain text.
 Due to technical limits the maximum number of vertical dots is 32.
For this the maximum size of data matrix codes is also determined
by this limit. Using a rectangle data matrix code may be a work
around.
8.7.1.2 Bar codes: Object creation and properties
Please see point 1 of Figure 148
In the job editor you can create an <Bar code> object either with the <Insert>
drop-down menu (1) or with the direct button (icon) for <Bar codes> (2).
Both will open the dialog box for the object settings (3).
